Fluorine Extruded ETFE High Temperature Cable Extrusion Line

Fluorine Plastics FEP/FPA/ETFE High Temperature Cable Extrusion Line

i-suntop Electric wire and cable equipments2022022...

1. Application for Fluorine Plastics FEP/FPA/ETFE High Temperature Cable Extrusion Line :

It is suitable for extruding FEP(Fluorinated Ethylene Propylene, also known as F46), FPA and ETFE (also known as F40) etc. Fluorine plastic production.

2. Specification for Fluorine Plastics FEP/FPA/ETFE High Temperature Cable Extrusion Line :

Model	Screw Diameter	Screw L/D Ratio	Temperture Control	Main Machine Power	Extrusion Output kg/hr	Conductor Diameter	Insulation Back Outer Diameter	Electric Control
GF-30	Φ30	25:1 Special type screw	6 segment	10HP	15kg	0.1-3.0	0.3-4.0	Controlled inverter+PLC entire joumey control(may choose the use)
GF-45	Φ45	25:1 Special type screw	6 segment	15HP	25kg	0.2-6.0	0.4-8.0
GF-65	Φ65	25:1 Special type screw	7 segment	30HP	45kg	3.0-8.0	4.0-16.0
GF-90	Φ90	25:1 Special type screw	9 segment	37HP	70kg		8.0-20.0

3. Characteristics for Fluorine Plastics FEP/FPA/ETFE High Temperature Cable Extrusion Line :

Screw barrel: Adopt new No.3 steel GH113 (With the Untied States GDA material) corrosion resistant and high temperature resistant.

Crosshead: Adopt new No.3 king steel GH113 material special fixed centering crosshead or manual centering crosshead.

Heating system: Adopt high temperture resistant copper alloys heater.

Quality control: Equipped with diameter inspection feedback device, full process control of product outer diameter and concentricity diameter.

Electronic control: Imported converter + PLC touch screen control.

Fluorine Extruded ETFE High Temperature Cable Extrusion Line
